At this point the stanchion is extended to the fork-top which is screwed in. Do not tighten at this time Baron recommends the use of blue Loctite on this bolt. Set floorboard angle by installing flathead allen adjusting screw in the pivot bracket at the desired angle hole. Baron floorboards set to a 15-degree position has been found to be most comfortable and user friendly. Adjust side tilt angle by moving floorboard stop screw in or out to achieve desired angle.
Floorboard is ready for installation. Remove the nuts that attach your stock passenger peg mounting brackets to the frame and remove stock pegs. Install your new Baron floorboards in the same location using supplied M8 mounting bolts and washers. Be sure you dont over-tighten these bolts. It is best to use Loctite when mounting. Adjustment of Floorboard Angle After Installation 1. Remove the small allen screw located on visible side of the cam bracket.
Once this screw is removed, adjust the cam to the desired hole and insert and tighten allen screw. Repeat process on both sides.
Grab your horsepower today. We love Rob Muzzy and Muzzy Exhausts. Going back to Doug Chandler and Scott Russell, Muzzy has been synonomous with Kawasaki and performance — and for years, if you rode Kawasaki,and you were on the podium, Muzzy was on your exhaust. We also feature Arrow and Yoshimura exhausts for your ZX-6R, ZX-10 and ZX-14.
We love the sound of a Yosh exhaust on any Kawasaki Ninja. Bolt-On style bolts to the O. Increase horsepower and torque throughout the entire rpm range.
Lightweight, strong stainless steel header design looks great and weighs less than stock headers. Generated: 19 October, 2010, 12:28 Hindle Stainless Exhaust Low Head Pipes — Kawasaki ZX9R 00-03 The worlds lightest stainless steel exhaust system. Increase horsepower and torque throughout the entire rpm range. Lightweight, strong stainless steel header design looks great and weighs less than stock headers. Remove both saddlebags by removing the 3 bolts shown below Remove the plastic liner in the bottom of the trunk by gently pushing in on the center of the plastic clips Once the liner is removed remove the trunk rear light assembly by removing the 4 black screws in side the trunk and 4 on the bottom side of the light assembly.
Unplug the light assembly and set it aside. Remove the bolts for the trunk Have a friend hold the trunk up and remove the 4 screws two on each side for the side trim Put the bolts back inside the trunk and tighten finger tight to make sure it does not fall. Remove the remaining side trim screws, 5 on each side, and remove the side trim and set it aside Remove 2 bolts from the saddle bag supports. Place the side plate mounting bracket behind the saddlebag supports and replace the two bolts you removed in the previous step.
We recommend using a few drops of Loctite. Do this step for both sides of the bike. The opposite way that you would normally unscrew something To do that I recommend using, either a rubber strap wrench, ora sheet of thin rubber used as you would to loosen the lid of ajar.
Once Ihadtheend caps off, I used a sharp utility knife to cut through, and peel off the factory rubber grips. With the rubber grips off, I removed the chromed ring that is adjacent to the left switch housing. The chromed plastic ring next to the switch housing needs to be cut off. Note all the ridges on the sleeve, all these except one ridge need to be filed off.
Prepare left handlebar for grip installation The left handlebar is pretty easy to prepare, first I cleaned any glue from the bar, and then gently test fit the left grip, be very careful here as it needs to slide on easily. Remember after the test fit you need to take it off again. If you find it too tight, as I did sand the bar using sandpaper until it slides on and off easily.
This is necessary to be able to remount rear fender. Locate two threaded holes 6mm near the top of the sub frame. Bolt top of bracket A to these holes.
Attach brackets to hitch. Remove the false fuel tank cover to expose the battery. Remove the right hand lower leg fairing. Unplug the stock horn and remove the 2 10mm bolts securing it to the frame. See photo 1 using the stock horn bolts attach the black horn mounting bracket and the white ground wire supplied as shown.
Next locate the relay supplied. Attach the air hose to the compressor air outlet fitting. Attach the short red wire supplied to the compressors positive + terminal and the white wire installed earlier to the compressors ground - terminal. As shown in photo 2. Attach the compressor to the frame with the hose clamp provided. Also the air hose and fitting should be in front of the frame tube with the hose routed inside the hose clamp without pinching the hose.
Attach the red wire from the compressor to one of the relays remaining outer terminals 30 or 87. Attach the remaining long red wire supplied to the remaining relay terminal 30 or 87. Secure the relay to the frame with a cable tie supplied. Route the red wire up to the battery positive + terminal. Locate the fuse wire assembly provided. Attach the fork end of the fuse wire to the battery positive + terminal. Cut the red wire to the desired length, strip the end and crimp to the fuse assembly.
Turn on the ignition and press the horn button, you should hear the compressor motor run. Re-install the false fuel tank lid. Re-install the right lower leg fairing while routing the air hose out next to the black horn mounting bracket 4. Trim the air hose to length if necessary and attach the air hose to the horn assembly. Install the trumpet covers. If you are installing the relocation arms at the same time as the floorboards follow their instructions first and then refer to this sheet.
Fold the floorboards up, remove the allen screws that attach them to the round spacers, remove the floorboards and set aside. Install the left and right relocation arms marked with an L and R on the back side onto the pins of the round spacers in the upper or lower position as desired.
Using the allen screws and washers supplied bolt the arms to the round spacers and tighten securely. Re-install the floorboards onto the relocation arms placing the supplied dowel pins into the set of holes on the relocation arms that allow the floorboards to be level or parallel with the ground.
Install and tighten the allen screws removed earlier 1. Remove the driver board pivot bolts and lock nuts. Install the new driver board in the same locations as the stock boards were removed from. Install the bolts and lock nuts. The driver board bolts should be tightened only enough to seat the nut and bolt head. The driver boards should pivot up approximately 20 degrees freely. Check that the lock nuts are secure.
